Product Details:

Place of Origin: Fujian, China
Brand Name: ELSONIC
Model Number: RE001

Payment & Shipping Terms:

Minimum Order Quantity: 100 units
Price: $8.00 - $10.00/units
Packaging Details: Floor Heating Thermostats1 UNIT/BOX SIZE: 11.5*10*7CM 84 UNIT/CARTON SIZE: 58*44*42CM
Payment Terms: T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow
Supply Ability: 100000 Set/Sets per Month
Get Best Price Contact Now

Detail Information
Color: White Type: Floor Heating Parts, Floor Heating Thermostats
Floor Heating Part Type: Floor Heating Thermostats Application: Water Heating/Electric Heating System/Boiler
Power Supply: 24VAC/110VAC/220VAC Display Accuracy: 0.5℃
Temperature Range: 5~35℃ Programmable: 5+2 Four Periods
Sensor: Internal Or External Communication: WIFI / RS485 / Modbus / Zigbee
Installation Box: 86*86mm Or European 60mm Round Box Current Load: 3A/16A
Port: Xiamen, China

Product Description

RE001 Weekly Programmable Floor Heating Thermostat



Apply to water heating system-RE001GA



Apply to electric heating system-RE001GB



Streamline design with LCD clear display



Menu-driven programming makes setup effectless



With NTC10K temperature sensor



Memory function for setting



White backlight simple but upscale



Compact design, suitable for any household collocation.



Perfectly fits for Eu-Standard installation box



Large-screen LCD display,white backlight



Compact design



Streamline design



High reliability MCU





General
RE001 Weekly Programmable Floor Heating Thermostat adopt NTC sensor, Output relay controls the on/off of the motorized valve. When room temperature is 1 lower than set-point, thermostat opens the valve; when they are equal, it closed the valve. The max. current load is 16A. With computerized controller technique. R8600 Series Thermostats hava Timing Open/Close and 7days 4 cycle programmable function. LED displays room temperature and set-point mode.



Technical Data

Sensor

NTC

Power Supply

AC220V ± 15%, 50/60 HZ

Temperature Range

5-35. ºC

Temperature Control Accuracy

±0.5 .

Output Power

AC220V2A for heating, AC220V16A for electric heating

Shell

PC+ABS (Fire-proof)





Characteristics

- Nice design.

- Easy operation

- NTC Sensor, accurate Temperature Measurement

- Light guide botton

- Dual temperature dual controller. (optional)

- Control mode: Time Period Programmable, manual/temporary controlling.
