AC806 HVAC Room Thermostat 0.5C Display Accuracy Max Load 2A Devices
Product Details:
| Place of Origin: | Fujian, China |
| Brand Name: | ELSONIC |
| Model Number: | AC806 |
Payment & Shipping Terms:
| Price: | $10.00 - $30.00/pieces |
|---|---|
| Packaging Details: | Thermostats1 UNIT/BOX SIZE: 11.5*10*7CM 84 UNIT/CARTON SIZE: 58*44*42CM |
| Payment Terms: | T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow |
| Supply Ability: | 500000 Piece/Pieces per Month |
|
Detail Information |
|||
| Type: | HVAC Systems,Thermostat | Application: | FCU/Central Air Conditioning |
|---|---|---|---|
| Power Supply: | 24VAC/110VAC/220VAC | Max Load: | Inductive 2A, Resistive 4A(5A Rating Relay) |
| Display Accuracy: | 0.5℃ | Temperature Range: | 5~35℃ |
| Product Color: | White | Ambiente: | Storage:-20C~60C, Ambient Operating: 0°C To 50°C, Humidity:5~95% |
| Suitable System: | Two Pipe/Four Pipe | Communication: | WIFI / RS485 / Modbus / Zigbee |
| Port: | Xiamen | ||
Product Description
Digital Fan Coil Unit Thermostats
Specification
|
Rated voltage |
220V AC,24V AC |
|
Rated Current |
3A |
|
Power Cunsumption |
<=1.5W |
|
Set-point Range |
5-35°C10~30°C |
|
Accuracy |
±1ºC |
|
Measured Temperature |
1-40 1~50 ºC |
|
Accuracy |
at 25<=1oC |
|
Shell |
White PC plastic |
|
Ambient Condition |
-5 ºC~ 55 ºC |
|
Relative Humidity |
<92%(no condensing) |
Characteristics
|
- NTC |
|
- Large digital LCD display with blue, orange or back light |
|
- Fashionable and smart design, simple operation screen |
|
- Shows accurate room temperature and set point |
|
- Easy calibration function |
|
- Various models of time display |
|
- 5V power, 8-hour timing turn on / off |
|
- Steady working relay output control |
|
- +1°C control accuracy ratio, +0.1°C temperature accuracy resolution ration |
|
- Optional infrared remote control |
FUNCTION
|
Programs the set point in one week and optional timing turn on / off |
|
Optional sleeping function, comfortable degree |
|
Automatic data memory and restarting after the power returns |
|
Automatically or manually control fan speed |
|
Low temperature protection, will not freeze |
|
Normally open / close signal output |
|
Connects to motorized valves, solenoid valves, and fan valves |
|
Applications: detects and controls room temperature in commercial, industrial and residential environment, automatically keeps the roomtemperature stable |
|
Connects to main system, communication and multioutput functions |
